Şişecam Climax T 71

Şişecam ClimaX T 71, also known as Şişecam Temperable Low-E Glass Neutral 71/53, is temperable coated glass with high light transmission and thermal insulation.

It preserves natural daylight and a transparent appearance while allowing substantial solar heat gain. Its temperability makes it suitable for architectural applications requiring safety glass.

Product Features

• A temperable Low-E coated glass solution developed by Şişecam.
• Its thermal insulation helps reduce the heating load of buildings.
• High light transmission enables effective use of natural daylight indoors.
• Its transparent, neutral appearance helps maintain a visual connection with the outdoors.
• It allows solar heat into interior spaces for substantial passive solar gain.
• Its temperability makes it suitable for glazing applications requiring safety glass.

Technical Performance Values

• Light transmission: At least 60%
• U-value: Above 1
• Solar factor: At least 40%
• Shading coefficient: At least 40%
• Temperability: Temperlemeye uygundur

Applications

Şişecam ClimaX T 71 is suitable for homes, schools, hotels and hospitals where natural light, thermal insulation and safety are important.

Manufacturing Method

Şişecam ClimaX T 71 is an offline coated glass produced by electron sputtering onto float glass in a vacuum.

A very thin metal or metal oxide layer is applied to the float glass to combine thermal insulation, high light transmission, a neutral appearance and solar heat gain.

Size and Thickness Options

Şişecam ClimaX T 71 is produced in the following standard thicknesses:

• 4 mm
• 6 mm
• 8 mm

Standard sheet sizes are:

• 3210 × 2250 mm
• 3210 × 2500 mm
• 3210 × 6000 mm

The size tolerance for all nominal dimensions is ±5 mm. Contact us for sizes or thicknesses outside the standard options.

Quality Standard

Şişecam ClimaX T 71 is produced in accordance with TS EN 1096, Glass in Building – Coated Glass.
